0603USB Series Common Mode Choke Optimized for USB 3.0, HDMI, IEEE 1394 and LVDS applications

Cary, IL, USA - Coilcraft’s 0603USB Series Common Mode Chokes virtually eliminate common mode noise in high-speed, differential mode signal transmission applications such as USB 3.0, HDMI, SATA, IEEE1394 and LVDS, supporting data rates up to 4.8 Gbit/s.

0603USBThese miniature chokes feature an EIA 0603 footprint and measure just 1.07 mm tall. Most values provide greater than
15 dB common mode attenuation and greater than 100 ohms impedance. The 0603USB Series is RoHS compliant and offers a maximum reflow temperature of 260°C. It features gold over nickel over silver-palladium-glass frit terminations.

As with all Coilcraft parts, complete technical specifications and free evaluation samples for the 0603USB Series are available online at To further assist engineers in the design process, Coilcraft offers a free Common Mode Filter Design Guide on its website, as well as a low cost Designer’s Kit containing a complete range of samples for its 0603USB, 0805USB and 1206USB product series.

Parts are available from stock and can be ordered on-line at or by calling a local Coilcraft sales office.

For more information, contact Len Crane, +1-847-639-6400,
