The XEL40xx Series is offered with lower inductance values (as low as 92 nH) that have been fully optimized for high frequency applications. They also offer extremely low DCR (as low as 2.5 mOhms) and ultra-low AC losses, resulting in the highest efficiency across a range of frequencies (2 to 5+ MHz). They are offered with current ratings as high as 28.5 Amps, and their soft saturation characteristics can withstand high current spikes.
XEL40xx Series inductors measure just 4.0 mm square with maximum heights as low as 1.2 mm, making them ideal for IoT and portable device applications. They feature RoHS compliant tin-silver over copper terminations and are halogen free. The XEL4014 and XEL4020 models are qualified to AEC-Q200 Grade 1 standards (-40° to +125°C ambient), making them suitable for automotive and other harsh-environment applications.
Headquartered outside of Chicago in Cary, Illinois, Coilcraft is a leading global supplier of magnetic components including high performance RF chip inductors, power magnetics and filters. In addition to a large selection of standard components, Coilcraft also designs and builds custom magnetics to fit a customer’s exact electrical requirements.
Engineers and buyers consider Coilcraft a preferred supplier because of its reputation for quality, reliable delivery, engineering support and the superior performance of our products. In independent surveys, engineers consistently rank Coilcraft the number one magnetics company they would recommend to a friend.
