November 11, 2014

Coilcraft Magnetically Shielded Power Inductors Offered in High Inductance and High Isat Versions

Cary, IL, USA — Coilcraft’s XAL15xx Family of rugged, magnetically-shielded power inductors are offered in two versions – one providing saturation current ratings up to 111 Amps and the other offering inductance values as high as 33 µH – delivering the highest levels of performance in the smallest possible space.

XAL15xxThe XAL1510 Series offers a unique combination of high inductance values (up to 33 µH) and current rating as high as 39.0 Amps, all in a compact package that measures just 15.4 X 16.4 mm and has a maximum height of 11.0 mm. For even higher current applications, the XAL1580 Series offers Isat ratings up to 111 Amps, with a 15.2 X 16.2 mm footprint and maximum height of 8.2 mm.

Both series offer very low DCR - down to 0.70 mOhms for the XAL1580 - and their soft saturation characteristics make them ideal for VRM/VRD applications. They feature RoHS compliant tin-silver (96.5/3.5) over copper terminations and offer a maximum reflow temperature of 260°C. And like all Coilcraft XAL/XFL inductors, the XAL1510 and XAL1580 Series feature a proprietary composite core that is not subject to thermal aging issues associated with other iron powder core inductors.

As with all Coilcraft parts, free evaluation samples and complete technical specifications are available online at Parts are available from stock and can be ordered on-line at or by calling a local Coilcraft sales office.

For more information, contact Len Crane, +1-847-639-6400,

About Coilcraft

Headquartered outside of Chicago in Cary, Illinois, Coilcraft is a leading global supplier of magnetic components including high performance RF chip inductors, power magnetics and filters. In addition to a large selection of standard components, Coilcraft also designs and builds custom magnetics to fit a customer’s exact electrical requirements.

Engineers and buyers consider Coilcraft a preferred supplier because of its reputation for quality, reliable delivery, engineering support and the superior performance of our products. In independent surveys, engineers consistently rank Coilcraft the number one magnetics company they would recommend to a friend.

1102 Silver Lake Road
Cary, IL 60013 USA
Fax +1-847-639-1469
